#PH208
PH208 - pH METER
#PH208
PH208 - pH METER
$258.00*
*15% GST applicable for sales within NZ
Product Description
- Professional PH/mV METER.
- PH range : 0 to 14 PH x 0.01 PH.
- mV range : -1999 mV to 1999 mV.
- Used the optional ORP probe to become a professional ORP meter.
- Wide manual temperature compensation adjustment can be operated by push button on the front panel easily.
- Calibration for pH 7, pH 4 and pH 10 by push button.
- Temperature compensation of pH function can be done by optional ATC (Automatic Temperature Compensation) probe.
- Auto shut off saves battery life.
- Memorize Max./Min. reading with recall.
- Data hold.
- RS232 computer interface.
The PH-208 pH/mV Meter offers accurate and reliable measurements with advanced features, making it an essential tool for various applications in laboratories, aquariums, and more.
Exceptional Features of the PH-208:
1. Multi-Function Measurement: Measures pH and mV, providing comprehensive testing capabilities for various applications.
2. Manual and Automatic Temperature Compensation: Wide temperature compensation range with both manual and optional automatic options, ensuring accurate readings under varying conditions.
3. Microprocessor Circuit: Ensures high accuracy and provides special functions such as data hold, maximum/minimum readings recall, and auto power-off to save battery life.
4. RS232 PC Serial Interface: Equipped with an RS232 interface for easy data transfer to a computer, facilitating further analysis and record-keeping.
5. Durable and Portable Design: Features a large LCD dual-function display and a strong, lightweight ABS-plastic housing case, making it easy to carry and operate in various environments.
Versatile Applications:
Ideal for use in aquariums, food processing, beverage industry, photography, fish hatcheries, laboratories, paper industry, schools, colleges, plating industry, swimming pools, quality control, and water conditioning.
Specifications
| Display | 51 mm x 32 mm, dual function LCD display, 15 mm ( 0.6" ) digit size. |
| Measurement | pH : 0 to 14 pH mV : -1999 mV to 1999 mV |
| Accuracy | ± (0.02 pH + 2 d) * Meter only ± (0.02 pH + 2 d) * Meter only |
| Input Impedance PH range Temp | 10^12 ohm |
| Sampling Time | Approx. 0.8 second. |
| Operating Temperature | 0 °C to 50 °C (32 °F to 122 °F). |
| Operating Humidity | Max. 80% RH. |
| Power Supply | 006P DC 9V battery (Optional) ( Alkaline or Heavy duty type ). |
| Weight PH electrode | 250 g/0.55 LB ( battery included ). |
| PH range Temp. Compensation | Manual : 0 to 100 , be ad °C justed by push button on front panel. Automatic( ATC ) : With the optional TEMP. probe ( TP-07 ) 0 to 65 . °C |
| PH electrode ( Optional ) | Optional, Any pH electrode with BNC connector. |
| Resolution | 0.01 pH 1 mV |
| Data Hold | Hold the reading value on the display. |
| Memory Recall | Maximum and Minimum reading values can be saved and retrieved by record function. |
| pH Calibration | pH7, pH4, and pH10, 3 points calibration ensure the best linearity and accuracy. |
| Power off | Auto shut off saves battery life, or manual off by push button. |
| Standard Accessories | Instruction manual : 1 PC. |
